Operating a Nest thermostat is one of the best ways to perfect the everyday schedule of your comfort system. This smart thermostat can recognize your preferences and automatically make improvements. But as you might expect, it won’t work well or at all if you see an error code appear. The exact error code supplies useful information about the root of the problem, something a professional technician can use to offer solutions that much quicker.
Here are seven of the most frequent error codes you may encounter on your Nest thermostat. We’ll walk you through the basics of each error code along with how you can address it and the projected cost to do so. Remember that while the costs will ultimately hinge on the exact Nest model, you can anticipate paying between $75-$200 for repairs. This should also cover travel and labor costs on top of any specific hardware needed to complete repairs.
e298 – Critical
This critical error code is limited to new models of the Nest thermostat and shows up when the power is shut off. Since this is a critical power error, the thermostat will change to the backup battery system. The error message will remain on the screen until the issue is fixed.
Losing power to your Nest thermostat can be for numerous reasons. The wiring could have disconnected or become damaged, or a disconnection may have occurred further along in your home’s electrical system. This might be the circuit breaker, fuse box or system switch. A professional technician will check electrical connections and wiring until they find the source of the problem.
e294 – Critical
Critical error code e294 is displayed when your Nest thermostat’s wiring should be reconfigured. More specifically, the technician will need to reconfigure the R wire. They’ll first conduct a factory reset of your thermostat to ensure it’s not simply a software error. If that doesn’t work, they’ll review the wiring diagram of the thermostat and begin inspecting connectors.
They’ll detach the power and slowly check each wire, seeing to it that they are fully inserted into the connector with the correct amount of uncovered copper. After they locate the problem connector, it can be replaced for a new one.
e195 – Critical
This critical error code can appear when the weather outside is especially hot. The HVAC system can break down and stop delivering power to your Nest thermostat. When this problem lasts, the backup battery in your thermostat drains and the thermostat will subsequently turn off. Presuming the breakers are on, you can examine a handful of other places before contacting a professional technician.
Since this error can drain your thermostat’s battery, the first step may be restoring enough power to figure out if this specific error code is what you’re facing. You can detach the thermostat from its base and deliver power by using a USB cable. Assuming it presents error code 195, you can continue to visually check components such as the wiring as well as your air conditioner’s air filter or drainage system. If you struggle to detect anything wrong with these components, it will probably be best to contact a pro.
e103 – Critical
Another critical error code, e103 suggests an electrical error with your Nest thermostat. More specifically, e103 will refer to an overcurrent problem, which means the wiring is receiving more power than necessary. This can stem from the breaker box, an error from the control board or through a defective connection in the thermostat. A technician will cautiously examine and test the Nest’s electrical system to understand where the power is surging or why the thermostat believes there’s an overcurrent problem.
n260
Even though this error code isn’t critical, it can still keep you from using the Nest thermostat like normal. Error code n260 concerns the lack of a C wire or Nest Power Connector, as not having one can block your Nest from getting adequate power. You can examine the Nest’s C connector for the presence of a C wire and modify the wiring itself if there is. If not, you need a Nest Power Connector.
Due to installation of a Nest Power Connector, you will sometimes notice error code E297 show up. This can be resolved by updating your thermostat in Settings -> Software -> Update. If the Power Connector is already installed, you’ll instead need to update the wiring info in the app from Settings -> Thermostat -> Wiring -> Update wiring.
e104 – Critical
Similar to error code e103, e104 is a critical error that’s the result of an overcurrent. If excessive power is sent using the Nest’s wiring, it may damage internal components and could even be a fire hazard. If you notice this error code appear on your Nest thermostat and want to guard against electrical damage, it’s recommended to turn the power off as soon as possible. You can then contact a professional technician with the appropriate experience diagnosing and fixing electrical issues.
e73 – Critical
When your thermostat displays error code e73, it signifies that the Rc wire is not getting power.
This will sometimes be as straightforward as the breaker being switched off, but it may also be a problem with the wiring. After switching off the power to your HVAC system and thermostat, you can visually inspect the wires to make sure nothing is loose or damaged. If nothing appears to be out of place, it’s a good idea to speak with a local professional.
